Product detail:
Welded wire mesh
1. Material: High-quality low-carbon steel wire, stainless steel wire.
2. Knitting: First weaving then plating, or plating before weaving, and the hot dip galvanizing, electro-galvanized, PVC plastic, special-welded wire mesh.
3. Performance : With strong antioxidant, and other anti-corrosion characteristics.
4. Uses : Widely used in industry, agriculture, construction, transport, mining, stadium, lawn, aquaculture, and other industries fence, decoration, mechanical protection.
5. Application: This kind of product is widely used in industry, agriculture.,construction,transportation.etc
Specification List of Welded Wire Mesh | ||
Opening | Wire Diameter(BWG) | |
In inch | In metric unit(mm) | |
1/4" x 1/4" | 6.4mm x 6.4mm | 22,23,24 |
3/8" x 3/8" | 10.6mm x 10.6mm | 19,20,21,22 |
1/2" x 1/2" | 12.7mm x 12.7mm | 16,17,18,19,20,21,22,23 |
5/8" x 5/8" | 16mm x 16mm | 18,19,20,21, |
3/4" x 3/4" | 19.1mm x 19.1mm | 16,17,18,19,20,21 |
1" x 1/2" | 25.4mm x 12.7mm | 16,17,18,19,20,21 |
1-1/2" x 1-1/2" | 38mm x 38mm | 14,15,16,17,18,19 |
1" x 2" | 25.4mm x 50.8mm | 14,15,16 |
2" x 2" | 50.8mm x 50.8mm | 12,13,14,15,16 |
