2013 low cost diaphragm pressure transducer JSI-19 Factory supply

Brand:aa

Product detail:

2013 low cost diaphragm pressure transducer JSI-19 Factory supply

  OEM pressure transducer, Pressure sensing chip, Diaphragm pressure transducer





FEATURES

•  Compact structure
•  SS316L  case
•  Cost effective
•  High stability and reliablity
•  Small size



SPECIFICATIONS



Pressure medium	gas, liquid compatible to stainless steel
Pressure ranges	0 to 20,30...100Kpa, & 0 to 1,2,3...700bar  (0 to 3,5, 15....10000 psi)
Non-Linearity	± 0.3%FS
Power supply	1.5mA (0.5 to 2 mA)
Zero output	0±2 mV
Span output	100 ±30mV
Zero Temperature Error	±1%FS
Span temperature error	±1%FS
Over pressure	2X
Long time stability	0.1
Working temperature	-40 to 125°c
Storage temperature	-40 to 125 °c
Compensation	-10 to 80 °c





DIMENSIONS

 Unit: mm







WHY US

1. 15 Years professional experience of pressure transducer manufacturing
2. Good quality assured by advanced manufactruing technology and quality management system
3. Low price benifit from economies of scale and industial engineering optimizing
4. ISO 9001, CE Approved, RoHS compatible
5. Quick response in 24 hours
6. Powerful sensor designing capability and all aspects customized service
