FST800-216 High Temperature Fusion Pressure Transmitter

Brand:aa

Product detail:





Product Introduction



The FST800-216 high-temperature pressure transmitter is a silicon MEMS strain gauge sensor which is glass bonded to a stainless steel diaphragm. It avoids influences on product caused by temperature, humidity, mechanical fatigue and medium, thus to improve its longterm stability in the industrial environment. Its pressure chamber is made of imported 17-4PH stainless steel in an integrated way without welding seams or O-rings and free of leakage troubles. Digital circuits capable of strong RFI & EMI resistance and automatic temperature compensation are installed inside the transmitter. The temperature compensation scope is from -40°C-150°C. The transmitter is featured with the strong interference resistance, wide working temperature scope, and longterm stability, etc. The series products provide several optional pressure connections and electric connections for customers.



Features



• Advance Microfused Silicon Strain Gauge, whole-designed elastomer, free of leakage troubles
• Heat radiation device installed, 150°C temperature compensation and capable of continuous operation under the high temperature
• Excellent resistance against impact, overload, shock and erosion
• Advanced digital temperature compensation and wide working temperature scope
• Highly-efficient lighting-absorption and strong RFI & EMI resistance
• High accuracy, high frequency response and longterm stability





Applicable Scope



• High-temperature and high-pressure medical disinfection
• Measuring of high-temperature media, like steam and hot oil, etc
• Measuring and control in the boiler industry
• Measuring and control of high-temperature pressure in other automatic systems







Project	Parameter
Standard Range	Pressure Type: gauge pressure  absolute pressure  sealed pressure
	Pressure Range(bar):1 1.6 2.5 4 6 10 16 25 40 60 100 160 200 250 300 400 500 600 750 1000 1500
	Pressure Range(psi):15 30 50 75 100 200 300 500 750 1K 1.5K 3K 5K 10K 15K 20K
Technical Index	Signal Output	4~20mA    0~5VDC      0~10VDC
	Signal Line Specification	2wire       3wire         3wire
	Supply Voltage	9~30VDC   9~30VDC     15~30VDC
	Accuracy	±0.3%FS  ±0.5%FS
	Zero Drift	±0.02%FS/°C
	Thermal Sensitivity Shift	±0.02%FS/°C
	Longterm Stability (1 Year)	±0.1%FS
	Frequency Response (-3dB)	3.2kHz
	Compensated Temperature	-40~+125°C
	Ambient Temperature	-40~+85°C
	Working Temperature	-40~+150°C
	Storage Temperature	-40~+125°C
	Overload Pressure	300% FS
	Burst Pressure	500% FS
	Mechanical Vibration	±20g
	Impact (11ms)	100g
	Environmental Protection	IP65
	Wetted Parts	17-4PH
	Electromagnetic compatibility (EMC)	EN61000-6
	Certificates	CE   RoHS









Price, Package, Service

1, Price : EXW,  FOBChangsha
2, Payment: 100% T/T in advance .
3, Packing : standard export packing , including instructions and certificate
4, Leading time : 7-10 working days.
5, OEM avaliable
6, Shipment: Express (FedEx, DHL, UPS & TNT) or forwarder
7. 7 days free replace & 1 year free repair for quality warranty
