Handheld ultrasonic flowmeter
RV-100H handheld ultrasonic flowmeter for various industrial field in the liquid flow-line measurement of calibration and inspection. Has high accuracy, consistency is good, battery-powered, simple operation and easy to carry and other features, is currently the smallest, lightest quality, truly portable ultrasonic flowmeter, the products have been exported to Japan, South Korea, Southeast Asia, Australia, the United States and other regions, has been widely praised.
Product Specifications:
Item | The Specifications of handheld ultrasonic flowmeter |
Linearity | 0.5% |
Accuracy | ±1% first to meet the accuracy in domestic |
Repeatability | 0.2% |
Response Time | 0-999 seconds, user-configurable |
Velocity | 0.01±32m/s |
Pipe Size | 15mm-6000mm |
Security | Setup values Modification Lockout. Access code needs unlocking |
Display | 4 lines English characters on-screen display instantaneous flow, velocity,, cumulative flow, signal status working hours and so on . |
Transducers | Model M1 for standard, other 3 models for optional |
Transducer Cord Length | Standard 2x10 meters, optional 2x 500 meters |
Power Supply | 3 AAA Ni-H built-in batteries. When fully recharged it will last over 10 hours of operation. 100V-240VAC for the charger |
Housing Material | ABS |
Size | Small size 220×92×32mm |
Weight | Light weight 538g with batteries |
Product Features:
Applicable to | Applicable for steel, stainless steel, cast steel, PVC, FRP and other uniform dense quality pipe |
Liquid types | water, sea water, sewage, alcohol, various oils such as uniform, single, stable liquid |
Output Signal | OCT output of positive and negative, the net cumulative pulse signal and frequency signal (1-9999Hz optional) |
Data Interface | RS232 interface is used for net testing or export the record data. RS-232C, baud-rate: from 75 to 57600. Protocol made by the manufacturer and compatible with that of the FUJI ultrasonic flow meter. User protocols can be made on enquiry. |
Straight pipe length | Upstream>10D,Downstream>5D, Length from pump exit>30D |
Data Logger | Built-in data logger can store over 2000 lines of data |
Optional sensors:
1.Standard Small stent sensors(DN15-100mm)
Fluid temperature: ≤ 110 Degrees
Dimension: 200 × 25 × 25mm
Handle Length: 100mm
2.Standard midsize stent sensors(DN50-DN700mm) (Magnetic)
Fluid temperature: ≤ 110 Degrees
Dimension: 280 × 40 × 40mm (2)
3.Standard midsize sensors M1(DN50-DN700mm) (Magnetic)
Fluid temperature: ≤ 110 Degrees
Dimensions: 80 × 70 × 55mm
4.Standard large size sensors L1(DN300 bove)
Fluid temperature: ≤ 110 Degrees
Dimensions: 60 × 45 × 45mm
