WTF wind alarm system for quay crane

Brand:aa

Product detail:

                   WTF wind alarm system for quay crane



WTF wind alarm system for quay crane used in the meteorological observatory (station), chemical industry, power station, Industrial and mining establishment to record the wind's traveling schedule and observe instantaneous wind speed installment. The wind alarm system( WTF wind alarm system for quay crane ) can realize the equipment wind speed instruction digitally and automatically. And it is essential sophisticated equipment for some modern equipment. WTF-B100 wind alarm system( WTF wind alarm system for quay crane ) is composed with STC12C2052 single-chip and its related periphery line, the display screen adopts two windows high brightness eight nixie tubes which can display currently actual wind speed and wind scale separately.

It's suitable for the different working conditions.







WTF wind alarm system for quay crane

Profile size	197.5mm x 90mm x 45mm
Work Power Supply	AC220V or DC24V/DC12V
Installation way	wall-mounted installation
Signal input	TTL voltage impulse/4-20mA



















WTF wind alarm system for quay crane



WFS-1 wind speed sensor’s parameter

Work power supply	DC12V	DC24V
Signal output	30 impulse per loop	4~20mA
Measure range	0~60m/s
Resolution rate	0.1m/s
Starting wind speed	<0.8m/s
Measure error	±(0.5+0.05v)m/s V= wind measure value
Work condition	-30°C~+60°C





WFS-1 wind speed sensor











One whole set of wind alarm system( WTF wind alarm system for quay crane ) listed as follows;

1. WTF-B100 Intelligent Display
2. WFS-1 Wind Speed Sensor
3. Cable (the length depends on your requests)

Installation Pictures;











Welcome to visit us!



Yichang WTAU Electronic Equipment Co. Ltd is a national high-tech enterprise which located in the “Hydropower capital”— Yichang. WTAU is committed to researching , developing and producing safety devices for crane cranes , automatic monitoring control systems , etc. WTAU puts the principle “make sure the lifting equipments are operated safely and reliably” as our duty and takes the high-tech as the core. WTAU has awarded many patents and major achievements of science and technology. The Load Moment Indicator,Overload Limiter, Anemometer ,Load cell,Wind speed sensor,limit switches,etc. which are researched independently are widely used in electrical, chemical, steel, metallurgy, construction, ports, shipping and other industries.



Any requests,please feel free to conact us!
