Click for original picture
Brand:aa
Product detail:
PERFORMANCE CHARACTERISTICS
1. High precision measurement of single phase AC frequency
2 Provide the digital tube display, local data query
3. Support for RS-485 communication, Modbus-RTU protocol
4. Support for switching input, output, analog quantity transmitting output
5. Auxiliary power supply: AC\DC 80V-270V, AC220V, AC380V, AC100V, DC48V, DC24V t
6. A variety of shapes, to meet the different requirements of the cabinet body electric circuit
TECHNICAL INDEX
1. accuracy of measurement:frequency ±0.02Hz |
2. Signal input:Connection mode of single phase |
Rated voltage of AC57.7V,AC100V,AC220V,AC380V |
Over load:voltage of 1.2 times( Continued ), times / second ( instantaneous ) |
Current of 1.2 times( Continued ), 2times / 1second ( instantaneous ) |
Power <1VA/ phase |
Impedance:voltage>300KΩ current <20mΩ |
Frequency: 45-65Hz |
3. Auxiliary power supply:Working range of AC\DC 80V-270V,AC220V,AC380V,AC100V,DC48V,DC24V |
Power consumption:<4VA |
4. Function module:Communication interface 1 way RS-485 communication, Modbus-RTU protocol |
Baud rate: 1200~9600bps, the default 2400bps |
Switch input support 2 stem node input |
The switch output support 2 relay output, capacity:AC250\5A,DC30V\5A |
Transmission output support 1 analog output:0\4-20mA or 0-5\10V |
5. Environment:Working temperature:-10°C ~+55°C |
Storage temperature:-25°C ~+70°C |
Relative humidity is less than 93%, no corrosive gas |
Elevation≤2500m |
6.safety:Insulation resistance >100MΩ |
AC withstand voltage AC2KV |
7. Electromagnetic compatibility:ESD level 4 |
Electrical fast transient burst level 4 |
Surge level 4 |
