2013 WANQI widely used hookah/shisha tablet press machine with high efficient

Brand:aa

Product detail:





Wanqi new style shisha tablet press, shisha tablet press machine, Hookah charcoal tablet press,shisha charcoal tablet









The brief introduction of shisha tablet press machine



Our shisha charcoal tablet press machine can press charcoal powder into round or square,
rectangular or other shape tablet.
The charcoal powder should be 80mesh and with moisture about 25%.





The shisha charcoal tablet press machine can press 40 times per minute, one time can press
8 pcs of tablet of diameter 50mm, 9pcs of tablet of diameter 40mm,or 14 pcs of tablet of diameter 3.8mm.
The shisha charcoal press machine can press 30000 pieces or so within one hour.





Feature of shisha charcoal from the charcoal tablet press
1.The shisha charcoal tablet is in good density, perfect shape, good appearance. Meanwhile,
it is easy for combustion, no smell and last longer when burning.
2.The shisha charcoal tablet diameter, density and hardness can be made as customer need.
3.The shisha charcoal is made of refined charcoal powder and Fragrance agent and edible binder.
4.The shisha charcoal tablet can be ignited with a match stick and when it is burning, there is no
smoke, no smell, no poison.





Today the most popular shisha charcoal is of round shape and diameter 30-40mm and thickness of 13mm.
You can change mould to press different shape of shisha charcoal.
 application of shisha charcoal tablet press machine
mainly used in charcoal industry, pharmacy, food and chemical industry











The features & advantages of shisha tablet press machine
1. The tablet press has a smooth surface.
2. The density can be adjusted and the pressure can be controlled easily.
3. The machine not only saves manpower and material resources, but also can redouble the product quality.
4. This machine is small and neat, but it has security alarm systems, vacuum function, and can rotating with frequency conversion stepless adjustment.



The application of shisha tablet press machine



The equipment is mainly used for charcoal powder, pharmaceutical, food, chemical and other industries. The machines are single pressure automatic tablet press, and able to suppress a variety of powdered materials into various shaped piece like round, square. The machine is designed according to GMP standard and packaged with stainless steel, easy to operate and maintenance. The machine has a small size and neat appearance, and a function of security alarm system, vacuuming, low noise characteristics. Its rotation is adjusted by stepless frequency.



Parameters :

Type	Parameters	Power  (Kw)	Dimension  (mm)	Weight  (t)
YPC-500 (Mechanical)	Mould diameter(mm):10,13,33,35,38,40,43,Thickness:5-30mm, Pressure :100T,30times/min,12pieces/once	7.5	1200×900×1500	2.5
YPC-600 (hydraulic)	Mould diameter(mm):10,13,33,35,38,40,43, Thickness:5-30mm, Pressure:160T, 40times/min,30pieces/once	4	1400×1400×1800	2
YPC-700 (disc)	Mould diameter(mm):10,13,33,35,38,40,43, Thickness:5-30mm, Pressure:200T, 10circles/min,20pieces/circle	5.5	1400×1400×1800	4

The product photos

YPC-500 Mechanical type

Our YPC-600 hydraulic type

Our YPC-700 disc type

The production flow:

Charcoal dust—crusher—conveyor—mixer—conveyor—charcoal briquette press—final product (Shisha charcoal)



The final products

Excellent after-sales service:

All our products will be maintained according to the “maintenance ordinance for guarantee of repair, replacement and refund of substandard”. Our company will send technicians to the users for installation, debugging and imparting technology during the warranty period (usually one year).

We will offer accessories freely in the first year and offer them permanently to ensure your satisfaction.

Before sale:

(1) Selection of equipment type.

(2) Design and manufacture products according to the special requirement of customers.

(3) Training technical personnel for customers

(4) Send technicians freely to users for site planning, optimal design process and scheme.

During sale:

(1) Acceptance check of products.

(2) Assist customers in drafting construction plan.

After sale:

(1) Appoint specialized after-sale service staff to users for installation and debugging.

(2) Install and debug the equipment.

(3) Train operating personnel.









                       If there is anything i can do for you, pls feel free to contact me.



                                                 Kelly is always at your service.



                                                 Your Success Is Our Business!
