Brand:aa
Product detail:
Function details:
ZCW353 Combination woodworking machine Feature:
1. Basic function: surface planer, thicknesser, miller, mortiser, sliding saw,
2. Compare with traditional multi-function woodworking machine, it is more big, and it has high working efficiency and accuracy.
3. It also has perfect appearance. Now more and more furniture factories turn to choose this type woodworking machine
4. 77mm planing arbor diameter with 4 planing knives
Specification:
Details of saw section |
| Vertical stroke | 60 mm |
Main saw speed | 4375rpm | Tool coupling diameter | 16 mm |
Main saw diameter | 300mm | Details of Surface Planer |
|
Spindle diameter of main saw | 30mm | Working table size | 1500 x 300 mm |
Scoring saw speed | 7000rpm | Spindle diameter | 70 mm |
Scoring saw diameter | 90mm | Spindle rotation speed | 5700 rpm |
Spindle diameter of scoring saw | 22mm | Knives | 3 pcs |
Motor power | 2.2kw | Min. work piece length | 15mm |
Aluminium table size | 1250*310mm | Max. planing depth | 4mm |
Details of Moulder section |
| Details of Thicknesser |
|
Spindle diameter | 30mm | Working bench size | 660 x 300 mm |
Max. tool diameter | 160mm | Min. work piece length | 200 mm |
Max. working thickness | 105mm | Max. removal thickness | 5.5 mm |
Spindle lifting stroke | 115mm | Feeding speed | 7 m/min |
Spindle speed | 4300/6000rpm | Max. planing thickness | 220 mm |
Motor power | 2.2kw | Min. planing thickness | 4 mm |
Details of Mortiser |
| Motor power | 2.2KW |
Working table size | 500*230mm | Total motor power | 6.6 Kw |
Longitudinal stroke | 200mm | Overall dimensions: | 1720*2650*1360mm |
Cross stroke | 100 mm | Net weight: | 580kg |
Packing details:
ZQM noly offers the machines with high quality. For the multi use woodworking mahcine, we only use the steady plywood case for packing, which can afford the long way ocean tranmission.
Workshop:
Promise:
All the cast iron parts are made by Raw iron, not similar with some one made by Scrap iron (the cast iron made by this is crisp and there are so many gas hole on the surface)
Any requirements pls feel free to contact me,tks!
