High efficient pellet machine for wood/sawdust

Brand:aa

Product detail:

Pellet machine for wood/sawdust is detailed as follows:





 Brief introduction of pellet mill :

JK series centrifugal pellet mill absorbs the advantages of worldwide pellet making machine, and designed with “double layer die” structure; The pinch roller is made of high alloy wear resistant materials. Transmission system oil filters automatically, and in good lubrication. This mill has the features of unique design, rational structure, low consumption high efficiency, sturdy and durable, and fill up the gap of round molding vertical feeding technology.

Type	Output(t/h)	Power	Standard	Weight	Size(mm)
JK450	Crude fibre0.4-0.7	55kw	Φ4-12mm	2.1t	1250*100*1600
JK560	Crude fibre1-1.5	90kw	Φ4-12mm	6.1t	2600*1300*2300
JK580	Crude fibre 1.5-2.5	160kw	Φ4-12mm	7t	2900*1300*2400
JK850	Crude fibre 2.5-3.5	220kw	Φ4-12mm	14.5t	3300*1400*3100
JK880	Crude fibre3-5	315kw	Φ4-12mm	18t	3800*1680*3400
JK1050	Crude fibre 5-8	360-450kw	Φ4-30mm
JK1250	Crude fibre 8-12	550-660kw	Φ4-30mm



Mould and roller:

Base of pellet machine:

 Application of pellet mill :

The equipments is applied to the material with low adhesiveness and low shaping.

Material:rice husk,sunflower seed husk,peanut shell and other fruit shell;branch,trunk,bark and other wood waste;a variety of corp straws,rubber,cement,ash and other chemical material.

Industry:It is used in the biomass energy fuels plant,power plant,wood processing plant,fertilizer plant,chemical plant etc.It is the ideal pressing shaping equipments with low





Main feature of pellet mill:

1.Vertical die,feeding vertically;No arching of raw materials,easy for heating dissipation.

2.Die fixed,rollers rotating,materials centrifugal,evenly distributed around.

3.Double-layer dies,up and down dual-use,high capacity,saving energy.

4.Independent lubrication;high pressure filtration,clean and unblocked.

5.Independent and frequency changeable cutting device,ensure formation rate of pellets.



                   Other main machinery for pellet mill production line:



Hammer mill

Cooling system:

Drying cooling system:

Packaging machine:

Our workshop:





 My name card:
