Brand:aa
Product detail:
Feature:
This machine connect several colors Flexographic between the blowing part and folding and rolling part in the blowing machine, so as to save time and strength, improve benefit. It is widely uses in blowing system each kind of low density polyethylene (LDPE), high density polyethylene (HDPE) and plastic membranes and so on linear low density polyethylene (LLDPE). As the liquid packing, printing compound, the clothing packaging and weaving packing, the industry packing.
Performance and Characteristics:
1) The extruder barrel and screw are use of high quality alloy steel, which deal with Nitride and precision treatment.
2) The Assist machine has a working platform to make the operation easy.
3) The rewinding unit use torque motor control, this can keep proper tension and make rewinding roller more flat and roller changing easy.
Optional Device:
1) Auto loader 2) Embossing roller 3) Film surface Corona treatment 4) Die rotary device
5) Air compressor 6) Mechanics screen changer 7) Up and down device 8) Double rewinding
Main Technical Specification:
Model | SJ-I 45 | SJ-I 55 | SJ-I 60 |
Screw Diameter(mm) | 45 | 55 | 60 |
Film Width(mm) | 600 | 800 | 1000 |
Printing Width(mm) | 600 | 800 | 1000 |
Output(kg/h) | 35 | 50 | 70 |
Printing Length(mm) | 250-1000 | 250-1000 | 250-1000 |
Screw L/D | 28:1 | 28:1 | 28:1 |
Film Thickness (mm) | 0.01-0.10 | 0.01-0.10 | 0.01-0.10 |
Blow Film Motor(kw) | 11 | 15 | 18.5 |
Total Power(kw) | 28 | 32 | 40 |
Weight (kg) | 4300 | 5000 | 6200 |
Size(m) | 7.5 x 2.0 x 3.2 | 8.0 x 2.4 x 4.0 | 8.5 x 2.6 x 4.6 |
