hydraulic hose crimping machine

I.D.of hoses(mm)

O.D.of Sleeve(mm)

before crimping

I   II    III  IV

O.D.of Sleeve (mm)

after crimping

I     II           III              IV

6

19 2123 25

17  18.8     20. 5      22

8

21 23 25 27.5

19  20.8     22.5       24.5

10

23 25 27 29.5

21  22.8     24.5       26.5

13

28 31 33 35

26 28.8      30.5       32

16

31 34 36 38

29  31.8     33.5       35

19

34 37 39 41

32   34.8    36.5       38

11

37 40 42 44

35  37. 8    39.5       41

25

41 43 45 47

39   40.8    42.5       44

32

49 51 53 55

47   48.8    50.5       58

38

55 57 59 61

53  54.8     56.5       58

51

68 70 72 74

66   67.8     69.5     71
