Industrial Flake Ice Machine 5Ton daily,High efficiency flake ice machine

Brand:aa

Product detail:

Industrial Flake Ice Machine 5Ton daily,High efficiency flake ice machine

--------------------------------

Specifications

Flake Ice Machine 5T  per 24hours
* Dry, sanitary, convenient, clean
* Beautiful in shape
* Achieve good preservation effect
* Extremely benefit storage and delivery



Flake ice machine application field
1 . Concrete cooling project
2 . Fishery and aquatic food processing
3.  Mine temperature reduction
4.  Food processing
5.  Artificial sking ground
6.  Medical facilities
7.  Dye chemical industry
8.  Medium and large chain supermarket
9.  Fresh preservation and cooling field application



HOILING COOL^®  Flake Ice Machine 5Tons

FLAKE ICE:

1. Directly formed at low temperatures,ice flakes are as cold as -8°C
2.Once formed,ice flakes are dry,clean,sanitary,convenient, beautifu in shape and not likely to lump
3. Relatively big contact area and good mobility can ensure their full contact with refrigerated objects to achieve good preservation effect
4. Without any sharp edges and corners,ice flakes cannot damage the surfaces of refrigerated objects but extremely benefit storage and delivery
5. The ice flaker is small-sized,light and convenient for use anytime

Fresh Water Flake Ice Machine Model

http://www.yangtzecooling.com/flake-ice-machine/index.html



Large ice machine 5T technical parameter

Subject	Technical parameter	Unit
Model	KC-5T
Ice output	5000	kg/24h
Bin capacity	3000	kg
Ref.capacity	28017	kca/h
Evaporating temperature	-22	°C
Total Power	23	kw
Power supply	3N/380v/50Hz	Phase/Voltage/Frequency
Refrigerant	R22/R404A
Cooling mode	Water cold
Unit dimension L*W*H	1600*1500*1480	mm
Bin size L*W*H	Subject to the actual needs of the customer	mm
Weight(exclude bin)	850	kg







INDUSTRIAL  ICE MAKER 5TONS









The Application Of Ice Machine:

http://www.yangtzecooling.com/application.html



+ Supermarket
- The flake ice produced by Yangtzecooling flake ice machine is widely applicable for all kinds of supermarkets,hotels and shopping malls to keep products fresh,Flake ice not only keep the frozen products from dehydration,maintain its original color,but also ensure the original taste of frozen products.Because flake ice is smooth and without obvious edges,which will not scratch the skin of frozen goods.



+ Seafood Hotels
The flake ice produced by Yangtzecooling flake ice machine is widely applicable for all kinds of seafood in hotels and shopping malls to keep products fresh,Flake ice can maintain its original color and taste without damaging the epidermis of the frozen goods.



+ Fruits,Vegetables Distribution and Preservation
- Application of vegetable processing: during the processing of agricultural products and vegetables harvested, flake ice reduced the speed of metabolism and growth of bacteria for agricultural products.Extend the shelf life of agricultural products and vegetables.
- Application of long-distance transport: ocean fishing, transportation of vegetables to freeze, fresh products is more and more widely used.



+ Marine Fisheries and Aquatic Products Processing
- Yangtzecooling flake ice machine plays a tremendous role in cold storage,transportation, processing of fresh seafood.Flake ice can not only provide appropriate environmental temperature,but also humid environment so as to keep seafood fresh and moist.



+ Slaughtering Industry
- With the improvement of people's living standards,food safety requirements are becoming more and more strict.Particularly on meat products export enterprise,each production process has strict requirements.Yangtzecooling Flake ice machine is specially designed for your demand of maintaining food fresh.



+ Food Processing
- Yangtzecooling flake ice machine has played a important role during the processing of bread,biscuits,dumplings,meat.There is a tremendous heat in the production process.Flake ice need to be used for temperature adjustment in order to ensure product quality.The method of temperature controlling is using ice flakes to control the temperature.For example,using ice flakes to quick lower the temperature to prevent fermentation during the bread production and processing.



+ Concrete Mixing Engineering
- The construction of large dams around the world and pouring concrete for the foundation of high-rise buildings need ice to control and maintain the temperature of mixing concrete. As heat evolution in the process of concrete hydration, the internal strength of concrete increases during the maintenance period, Hydration heat makes the temperature of concrete up to 25°C. After the maintenance, the concrete temperature drops,the volume reduces, as a result the cracks occur in the dam.Therefore,concrete pouring of the basis of every large concrete project needs a perfect pre-cooling system.



Standard operating condition:
1.Ambient temperature:25°C, Water temperature:15°C
2.Power Supply:3N/380V/50Hz, Supply Water Pressure:0.15-0.5MPa
3.Refrigerant:R22.R404A
4.Necessary Refrigeration Capacity Condition:Condensation temperature:40°C, Evaporation temperature:-22°C
5.The thickness of flake ice:1.5~3.0mm, Ice temperature:-8 °C
Technical data are subject to change without prior notice.





...
