Normal Flexographic Printing Machine for PP Woven Bag

Brand:aa

Product detail:



NORMAL FLEXOGRAPHIC PRINTING MACHINE FOR PP WOVEN SACK ML-RY4800



Main Technical Parameter:

Item     Type	Max.Diameter of unwinding roll(mm)	Max.Width of unwinding roll(mm)	Max. Printing width(mm)	Max. Printing length(mm)	Max. Printing color(mm)	Printing speed (m/min)	Gross power (kw)	Weight (kg)	Installing Dimensions (L*W*H) (kg)
MLB2800	1200	800	700	230-1200	2	5-50	10	2500	4000*1800*2200
MLB4800	1200	800	700	230-1200	4	5-50	12	3500	6000*1800*2400
MLB6800	1200	800	700	230-1200	6	5-50	15	4500	6000*1800*2400









Adopting soft sensitive resin as its printing plate. this kind of aniline printing machine can be used to print PP/PE woven cloth tube. PP/PE film tube. cellophane and web ,which is an ideal equipment for printing PP/PE woven cloth,non-woven cloth, shopping bags,vest bags as well as garment bags.







1 easy operation. flexible start . accurate register.







2 the meter-counter can preset printing quantity so that the machine stops automatically when the preset number is reached or the material is run out.







3 lift and lower the printing rollers manually or automatically and the printing ink can automatically stir after being lifted so as to avoid being dried and frozen.







4 the printing ink is transmitted by cobweb cylinder , which assures evenink color.







5 reliable drying system , high-speed running, automatic turnoff once the machine stops







6 360 continuous and adjustable longitudinal register plate







7 inverter motor for speed regulation adapts to different printing speed







8 buttons for "jog" and "stop" on roller base and rewin ding stand are convenient to operate the machine while installing the plates.















1.Have several senior engineers service in many countries, all the year round, with our after-sales office in countries.
2.Machines with quality guarantee for one year, life-long maintenance.
3.A lot of machines can be monitored via Internet, solve customer requirements immediately
4.Several senior engineers innovate and reform the technology continuous, in order to ensure the quality of mechanical stability.
5.Undertake various non-standard machinery, solve the customers' special requirements.
