1224 CNC Stone Engraving Machine

Brand:aa

Product detail:

Performance features:



1.Three axies adopt import linear orbit,two line sliding track,heavy loading,stable working,high precision,long lifetime.

2.Whole seamless weld steel structure,not easy to distort,the table back lining is armor plate, good rigidity,the machine can bear 1MT wight at least.

3.Well compatibility,compatible software CAD/CAM,such as Type 3,artcam, Castmate,wentai, Coreldraw.

4.Double direction cutters cooling system can prolong the lifetime of using.







Technical parameters :





Modle	RECI-9015	RECI-1218	RECI-1224
Working size	900*1500*250mm	1200*1800*250mm	1200*2400*250mm
Table size	1100mm*2000mm	1400mm*2300mm	1400mm*2900mm
Processing precision	0.05mm
Reposition precision	0.02mm
X Y structure	rack gear
Z structure	ball screw
Command	G code
Max idle speed	30m/min
Max engraving speed	5m/min
Working voltage	AC380V/50Hz
Spindle power	3KW/4.5KW/5.5KW/6KW/8KW
Spindle rotation speed	0-24000RPM
Drive motor	Stepper drive, servo (optional)
Operation motor	DSP





 Applicble industry:



Quarried stone,artcraft,tombstone,building,etc





Applicble materials:



Marble,glass,tile granite,white marble,sandstone,metals,etc.
