mineral water filling machine(3000-36000BPH)

Brand:aa

Product detail:

Our 3000-25000BPH water filling machine can be used for filling the mineral water. It also can fill the purified water, beverage, juice, soft drink and so on.



PROCSS FOR A COMPLETE BOTTLE FILLING LILNE:

1. automatic/semi-auto Blowing machine(include air compressor, air filter, air tank)

2. automatic bottle unscrambler or manual bottle uploader

3.3 in 1 wahing-filling-capping  machine:include the cap disinpection machine

4. light inspection

5. shrinking labeling machine

6.packing machine



TECHNICAL PARAMEERS:



MODEL	RCGF14125	RCGF18186	RCGF24248	RCGF323210	RCGF404012	RCGF505012	RCGF606015
washing/filling/ capping heads	14-12-5	18-18-6	24-24-8	32-32-10	40-40-12	50-50-12	60-60-15
production(500ml)BPH	3000-4000	5000-6000	8000-12000	12000-15000	15000-18000	18000-22000	20000-25000
motor power(KW)	6	6	7	9	13	16	19
size(LxWxH),(m)	2.25x1.6x2.3	2.3x1.7x2.3	2.9x1.9x2.3	4.3x3.5x2.3	4.3x3.9x2.3	4.6x3.9x2.3	5.1x4.6x2.3
weight	2800	3800	5000	6000	8000	10000	12000
