Product detail:
Hot sales JDT-9D electric wire cable making machine
Main Features:
The drawing machine body is iron casted, transmit by helical gear of high precision.
Drawing capstan is coated by tungsten carbide.
3-step DC annealing equipments.
PLC control wholly, mechanical speed synchronise with electrical speed.
Application:
It is applied for the production of Wire and cable industry , Metal wire processing, Oil cable industry , Automobile brake line,Musical instruments etc
Successful experience / Markets:
Be up to the international level. Our lines and related complete equipment have been exported to Southeast Asia,
West Asia, Eastern Europe, South America, the Middle East, Russia, India, Indonesia, Morocco, South Africa,
Algeria, etc.
JDT-9D copper rod breakdown machine
Machine model | JD-13D |
lnlet dia.(mm) | Φ4.0-3.0 |
Outlet dia(mm) | Φ1.00-Φ2.80 |
Drawing die number | 13 |
Main motor power | 30 |
Cone number | 2 |
Cone form | Two driving wheels |
Max drawing speed | 10 |
Annealing Type | Tubular type driving annealing |
Annealing voltage(V) | 0~55V(DC) |
Annealing current(A) | 0~1200A(DC) |
Conductive mode | Carbon brush |
Double take-up standard(mm) | PND500/560/630 |
Take-up motor power(KW) | 7.5×2 |
Optional equipments | Ring take up machine |
JDT--17D WIRE FORMING MACHINE
Machine model | JDT--250A—17D | JDT—250B—17D | JDT—250B—17D |
lnlet dia.(mm) | Φ2.60—Φ3.50 | Φ2.60—Φ3.50 | Φ2.60—Φ3.50 |
Outlet dia(mm) | Φ0.40—Φ1.20 | Φ0.40—Φ1.60 | Φ0.40—Φ2.00 |
Drawing die number | 17 | 17 | 17 |
Main motor(KW) | 37 | 55 | 55 |
Cone number | 4 | ||
Cone material | coated by tungsten carbide | ||
Max drawing speed | 2000 | ||
Take up machine motor | 11 | ||
Spooler diameter | Φ500/Φ630 | ||
Transmission type | grinding gear of high precision | ||
Body Structure | iron casted | ||
Annealing Structure | vertical or horizontal type (as your request) | ||
Max annealing voltage | 60V(DC) | 60V(DC) | 60V(DC) |
Max annealing currency | 2000A(DC) | 2000A(DC) | 2000A(DC) |
Brake type | pneumatic | pneumatic | pneumatic |
Take-up(optional) | Coiler machine | ||
Wire drawing machine auxiliary equipment
Hengshui Jinda electromechanical Co., Ltd. Specializes in wire drawing machine,
annealed wire machine and other drawing equipment accessories. Our company
has strong technical support, including 3 senior engineers, 8 engineers and 100 skilled workers.
The company can ensure product quality and reliable performance by advanced production technology.
Engineers for machine’s installation and debugging in Uzbekistan
For cable exhibition site:
