1200*900mm High quality cnc machine laser

Laser power :

80 /100/130W(RECI)

Laser tube life Span

8000-10000working/hours.

Applicable Materials

Acrylic,Glass,crystal,wood,leather,cloth,rubber,marble,ceramic,etc.

Working area:

1200*900 mm

Max moving speed:

6000mm/s

Laser energy control:

1-100% set by hand or software

Worktable:

Electric Up and down table. Up to 25 CM

Locating precision:

<0.01 mm

Min shaping character:

Character: 3*3 mm,; letter: 2*2 mm

Operating temperature:

5°C-35°C

Resolution ratio:

<4500 dpi

Laser type:

Hermetic CO2 glass tube

Power supply:

AC220±10%50 HZ/AC110±10%50 HZ

Control configuration:

DSP.

Data transfer interface:

USB (offline).

USB Ports

2

System environment:

WINDOWS 2000/WINDOWS XP/MAC/Vista

Cooling way:

Water cooling and protection system

Graphic format supported:

The file which CorelDraw, Photoshop, AutoCAD can identify(BMP,GIF,JPGE,PCX,TGA,TIFF,PLT,CDR,DMG,

DXP,PAT,CDT,CLK,DEX,CSL,CMX,AI,WPG,WMF,EMF,CGM,SVG,SVGZ,PCT,FMV,GEM,CMX).

USER MENU

Full English.

Package Inclusion

Software,VIDEO USER MENU CD,Air pump gun,Power cables, USB cables, Water tank,Water Pipe,Smoke Vent-pipe,Air Blow Pipe ,exhaust fan,Tools bag

Memory

64 MB

Display screen

LCD(SIZE 70*40 mm)

Protection System

Yes

Option parts

high-grade cooling system/double-head/cylinder rotary Jig/ irregular rotary Jig/ honeycomb table/ knifes table

Guarantee

1 year ,damageable spare parts(like laser tube,mirrors)  3 months

Dimensions

1480*1000*1080mm

Dimensions(package)

1600*1140*1300 mm

Net Weight

600KGs

Gross Weight

700KGs(wooden case)

Recommended Ship way

Air/sea
