Product detail:
Usage
The machine tool is widely used in processing and manufacturing of high-precision complex of electrical and instrumentation industry, automobile, motorcycle ,fasteners, bearing, photographic equipment, film machinery , hardware tools, watches, glasses, stationery, motors, valves and gas pipe and so on. It is best and the most efficient equipment of the hardware machining industry.
Description Model | Unit | CK6350Z | CK6150A,B,Z | |
Process andfeed | Maximum turning diameter | mm | 500 | 420 |
Maximum cutting diameter | mm | 400 | 250 | |
X-axis effective stroke | mm | 350 | 430 | |
Z-axis effective stroke | mm | 450 | 200 | |
X/Z-axis Leadscrew pitch | mm | 6 | 6 | |
X/Z-axis Leadscrew | mm | φ32 | φ32 | |
X/Z-axis Motor onlyport size | φ110/110 | φ110/110 | ||
Spindle andhydraulicchuck | Used spindle bearing | Import / Made in China | Import / Made in China | |
Taper of spindle bore | MT-6 | MT-6 | ||
Hydraulic chuck specifications | 250 | 250 | ||
Spindle speed | rpm | 400 | 800 | |
Recommended frequencyspindle motor | KW | 11 | 11/7.5 | |
Chuck androtary cylinder | Taiwan / China8inch | Taiwan / China8inch | ||
Spindle bore | Φ50 | φ50 | ||
Features ofthestructure | The layout of the formofthebed | 45° | 45° | |
Sliding the form of materials (hard rail / line rail) | Hard track | Hard track | ||
The standardhorizontalturretand propsquantity | Rotary cutter | The centeroftherow knife125 | ||
Shank size |
mm | 25×25 | 25×25 | |
Boring bar size |
mm | φ25 | φ25 | |
Used screw | Made in China / Taiwan | Made in China / Taiwan | ||
The use ofahydraulicunit | Made in China / Taiwan | Made in China / Taiwan | ||
Working Accuracy | X / Z positioning accuracy | 0.016/0.02 | ||
X/Z Repeat positioning accuracy | 0.007/0.01 | |||
Ovality | 0.008 | |||
Surface roughness | Ra≤0.8 | |||
Specification | Machine weight | kg | 3500 | 1900 |
Dimensions (length X width X height) |
mm | 2470×1510×1710 | 2230×1410×1650 | |
