160 tons pneumatic press

Brand:aa

Product detail:

JH21 series open back press with dry clutch and hydraulic overload protector



Feature of 160 tons pneumatic press

1) Welded body with steel plate and high intensity

2) Combined dry type pneumatic friction clutch and brake

3) Rectangle type hexagonal surface enlarged rail.

4) Manual shut height adjustment with scale display

5) Safety Duplex valves

6) Controlled by PLC from international brand.

7) Equipped with photoelectric protector for safe work. (Optional)

8) With CE certificate for European market.



Technical date of 160 tons pneumatic press

1	Type	JH21-160
2	Nominal force	1600KN
3	Stroke under nominal force	6mm
4	Ram stroke	160mm
5	Stroke time	40times/min
6	Max. mould height	350mm
7	Mould height adjustment	110mm
8	Distance from stroke surface to table	380mm
9	Working table dimension	740*1300mm
10	Bore size on the table	65*85mm
11	Thickness of working table	110mm
12	Distance between columns	850mm
13	Motor power	15KW
14	Dimension	2230 x 1630 x 3210mm
15	Net weight	14500kg



Photos of 160 tons pneumatic press



Mould:



We can supply eccentric press in various tonnages.

Please contact us for details.



We, Nantong Zhenhuan Trade Co., Ltd., are specialized in different kind of machines

for more than 9 years. We can provide you not only good quality punch press machine

but also good after-sale services.



Kindly please contact us to get more services and more information of

160 tons pneumatic press .
