economical bird cage mesh machine

Brand:aa

Product detail:



economical bird cage mesh machine



Welding wire diameter 2.0-3.0(mm)
Welding mesh size 25X20(mm)
Welding width 1200(mm)



Fields of application: to weld the meshes for cultivating cages, various  pet's cages and various

meshes of small specification.





Product features:



1,CNC wheel-step is designed  to provide the mesh grid with high accuracy.



2,Electrode lifting system is able to extend electrode life.



3,Line wire vertical straightening system can straighten the wire in high quality.



4,Unique high speed air cylinder used on welding electrode can provide high reliability.



5,Welding pressure steplessly adjusting applies to multiple wire diameter.



6,High speed mesh cutting system.



7,There are two choices for traction of  mesh. One is single car  to draw, the other is two cars to do by turns.



8,Straightening and sending of cross wires are completed by the automatically high-speed feeding system.



9,It is the most important that the equipment has high efficiency and be able to produce the high-quality meshes.



Technical parameters

Model	DNW-CNC1000		DNW-CNC1200		DNW-CNC1500
Installed power(kva)	3*60		3*80		4*80
System coltagte(v)	380V 50Hz		380V 50Hz		380V 50Hz
Control voltage(v)	24V		24V		24V
Max.mesh width	1000		1200		1500
Line wire spacing	≥20mm steplessly adjustable
Cross wire spacing	≥25mm steplessly adjustable
Wire diameter(mm)	2-3	2-3		2-3
Max.welding capacity	3+3	3+3		3+3
Max.wlding speed(time/min)	40-60	40-60		40-60
Max.welding spot nos.(group)	21	24		31
Pressed air(MPa )	≥0.8	≥0.8		≥0.8
Wire feeding method	coil feeding
Caterconer accutracy	≤2	≤2		≤2
Welding material	galvanized wire or cold drawing steel wire











































Photos of some components



Refering photos





If you have different requirements other than the above types, please kindly inform us about it and we will offer the

solution for you. Believe that if you are in need of the welding machine,you can get the satisfied ones from us.
