ZX-D3 bga rework station touch screen reballing manual best seller alignment motherboard repair mach

Brand:aa

Product detail:

ZX-D3 BGA rework station, alignment motherboard repair machine





Features:



1. With PLC user interface control, display actual temperature of three zone and a test temperature curve, can export temperature profile;

2. When welding,with CCD camera to monitor the melting process of solder ball;

3. With three independent temperature zone control, upper and bottom main heater with hot air to heat, third zone with infrared to preheat;

4. Three heater with 9 segment temperature up (down)+9 segment constant temperature control, can store 40 groups temperature curve;

5. Three heating zone with independent PID to control heating process, more stable and accurate;

6. Bottom heater and IR preheating zone with supporter to prevent welding zone part deformation;

7. After removal and welding with cooling fan to cool PCB board, ensure welding effect;

8. Temperature profile parameter with password protection;

9.  Equipped with a variety size of hot-air nozzle, or made according to special requirements;

10. Build-in vacuum pump, no need gas sources







SPECIFICATION:



PCB Size	Max L500*W300mm
PCB Thickness	0.1~5mm
Temperature Control	K thermocouple  PID Closed loop
PCB Positioning mode	Outer
Bottom preheat	Infrared  2400W
Main (Top+bottom) heater	Hot air  800W+800W
Power supply	Single phase  220V,50/60Hz,4.0KVA
Dimension	L650*W700*H550mm
Weight	Approx. 70kgs
