Brand:aa
Product detail:
KS100 Belt Driven Piston Air Compressor for Blowing Process
Specifications
1.Model: KS-100
2.Power: 10HP 7.5KW
3.Pressure:0.8Mpa
4.Capacity: 1m3/min
5.Tank: 200L
6.Suitable for 16 hours to work
7.ISO,CCC,ROHS
Application
This seires air compressor widely used in pneumatuic lock, pneumatic tool, tire inflation,blowing process,spray, paint,sand bklsting and fluidic element.
KS series compressor Technical Parameters
| . | Model | Motor Power HP/kW | Capacity m3/min | Working Pressure MPa(kg/cm2G) | Overall Dimention mm×mm×mm |
| 1 | KS10 | 1.5/1.1 | 0.08 | 0.8(8) | 810×240×800 |
| 2 | KS15 | 2.0/1.5 | 0.12 | 0.8(8) | 860×350×710 |
| 3 | KS20 | 3.0/2.2 | 0.18 | 0.8(8) | 980×370×800 |
| 4 | KS30 | 3.0/2.2 | 0.25 | 0.8(8) | 1000×450×750 |
| 5 | KS40 | 4.0/3 | 0.4 | 0.8(8) | 1500×520×1050 |
| 6 | KS55 | 5.5/4 | 0.55 | 0.8(8) | 1500×520×1050 |
| 7 | KS75 | 7.5/5.5 | 0.75 | 0.8(8) | 1600×570×1110 |
| 8 | KS100 | 10/7.5 | 1 | 0.8(8) | 1650×600×1200 |
| 9 | KS150 | 11/15 | 1.5 | 0.8(8) | 1850×650×1370 |
| 10 | KS200 | 20/15 | 2 | 0.8(8) | 1850×680×1420 |
| 11 | KS240 | 20/15 | 2.4 | 0.8(8) | 1850×710×1440 |
| 11 | W327-D1 | 25/18.5 | 3.2 | 0.7(7) | 1900×880×1650 |
| 12 | KSH30 | 3.0/2.2 | 0.21 | 1.25(12.5) | 1500×520×1050 |
| 13 | KSH40 | 4.0/3 | 0.3 | 1.25(12.5) | 1500×520×1050 |
| 14 | KSH55 | 5.5/4 | 0.45 | 1.25(12.5) | 1500×520×1050 |
| 15 | KSH75 | 7.5/5.5 | 0.6 | 1.25(12.5) | 1650×600×1200 |
| 16 | KSH100 | 10/7.5 | 0.8 | 1.25(12.5) | 1650×600×1200 |
| 17 | KSH100D | 10/7.5 | 1.05 | 1.0(10) | 1650×600×1200 |
| 18 | KSH150 | 11/15 | 1.2 | 1.25(12.5) | 1650×650×1400 |
| 19 | KSH150D | 11/15 | 1.6 | 1.0(10) | 1650×700×1400 |
| 20 | KSH200 | 20/15 | 1.7 | 1.25(12.5) | 1850×800×1550 |
