Product detail:
Specifications
chocolate conche machine
1.Capacity:500Litre
2.Power:15kw
3.turbo-driven
4.electric motor tighten grinding pressure
Use:
1).chocolate conche machine is one of the major chocolate equipment which is used for the fine grinding of chocolate material.
2).The fine grinding time is 14~20 hours for 500 litre, the average granularity can achieve 20μm.
3).This machine has many merits such as tight structure, easy operation, convenient maintenance, few one-off investment, and so on.
4).It is suitable especially for the technical request of small chocolate and candy factory.
Main parameter:
Maximum capacity: 1000 Litre
Fine grinding granularity: 20-25μm
Fine grinding time: 16-22 hour
Total power: 18.5kw
Net weight: 4100kg
Gross weight: 4300kg
Outside dimension: 2970*1320*1790mm
Option:1). Gear motor,hand tightening or electric tightening of adjustable grinding pressure.
2). Turbo motor,hand tightening or electric tightening of adjustable grinding pressure.
There are various models of chocolate conche as follows:
Model of machine | Maximum capacity | Fineness of chocolate (μm) | Fine grinding time | Overall power | Net weight(kg) | Outside dimension |
JY3000 | 3000 | 20-25 | 18-24 | 55 | 7000 | 3700*1900*2150 |
JY2000 | 2000 | 20-25 | 18-24 | 37 | 5250 | 3000*1900*1750 |
JY1000 | 1000 | 20-25 | 14-20 | 22 | 4100 | 2970*1320*1790 |
JY500 | 500 | 20-25 | 14-20 | 11 | 2900 | 2000*1860*1250 |
JY40 | 40 | 20-25 | 7-9 | 2.2 | 360 | 1000*800*800 |
