stainless steel vegetable drying oven/vegetabl dehydration hot air oven(0086-13838347135)

Brand:aa

Product detail:

        vegetable and fruit drying machine/fruit dryer machine



Introduction



AMS-D series hot air circulation oven adopts noise elimination and thermal stable axial flow fan and automatic temperature control system. The successful designmakes the heat efficiency increases from 3~7% of the traditional drying oven to 35~45% of the present one. The highest heat efficiency can be up to 50%.



 Features



1.Most hot air is circled inside the oven, high heat efficiency, save energy.
2. Equipped with forced ventilation and adjustable air distribution plates.



3. A wide selection of heat source such as steam, hot water, electricity, far infrared, etc.



4. Low machine noise, balance running process, automatic temperature control system, easy installation and maintenance.
5. Inside wall is stainless steel, outside wall is carbon steel (with nice cover painting).



6.Wide application.Such as food, vegetables,fruits,fish,shrimp,sea cucumber etc



Specification:



Model	Capacity each batch(kg)	Heating source	Power	Baking trays	Trollys	Diemension
AMS-D1	60	Electrical or steam	9	24	1	1380*1200*2000mm
AMS-D2	120	Electrical or steam	15	48	2	2260*1200*2000mm
AMS-D3	240	Electrical or steam	30	96	4	2260*2200*2000mm
AMS-D4	360	Electrical or steam	45	144	6	2260*3200*2000mm
AMS-D5	480	Electrical or steam	60	192	8	4280*2200*2270mm



 Machine pictures:



AMS-D1







AMS-D2







 AMS-D3





 AMS-D4





 AMS-D5







We have another type drying machine: vacuum freeze drying machine for fruit and vegetable for you to choose!







vacuum freeze drying machine for fruit and vegetable:







Features of the freeze drying machine:







1. compact conformation, convenient maintain, low price, full automatic control and convenient operation.







2. multi-function, can be used in many materials, like food, fruit, vegetable, fish, sea cucumber, etc







3. excellect design, low energy cost, only need to work by using electricity.







4. quickly drying with good result.







Specification:







Model	AMS-FD5	AMS-FD10	AMS-FD20	AMS-FD30	AMS-FD50	AMS-FD100
Control system	Automatic computer control, color crystal display all records
Material	304 stainless steel
Working method	Quick freezing, freezing drying
Drying area(Sqm)	5	10	20	30	50	100
Capacity(kg)	50	100	200	300	500	1000
Trays size(mm)	600*800*25	600*1000*25	600*1000*25	600*1000*25	600*1000*25	600*1000*25
Trays number	12	17	34	50	84	168
Power	16KW	28KW	45KW	60KW	90KW	180KW
