Product detail:
Kaishan KGH6 Mobile Crawler Down The Hole Drilling Rig Model (dia 105-104m)
1. New type feeding system
2. Famous brand engine
3. Reliable hydraulic pump set
4. Humanized design
A. Range of application:
(1Geological exploration; engineering geology investigation and kinds of survey hole in concrete structures.
(2)Diamond bits, hard metal bits and steel-shot could be selected to different layers.
(3The drilling depth which is 100m or 180m must be suitable for the final hole diameter 75mm 0r 46mm. The drilling depth could not exceed its 110%.
B. Feature of the drill:
(1)Easy operation and high efficiency as the hydraulic feeding be taken
(2)As the ball type chuck and the driving rod, it can complete no-stopping rotating while the spindle relift.
(3The pressure indicator of bottom hole can observe and control the well conditions easily.
(4)Close levers, convenient to operate.
(5Compact size and light in weight are easy to set up and transport on working plains and mountain area.
Characteristics
1. Security and stability of the running gear ·
2. Flexible boom
3. Reliable hydraulic pump group
4. reliable hydraulic system
Technical specification:
| Dia.of hole | 105-140mm |
| Optium drilling depth | 30m |
| Working pressure | 10.5-24.6bar |
| Air consumption | 15-25m3/min |
| Ground clearance | 320mm |
| Feed power | 10000N |
| Lift power | 22KN |
| Speed of rotator | 0-100rpm |
| Rotation torque | 4000N·M |
| Climb capacity | 30o |
| Traveling speed | 0-2.5km/h |
| Dimensions | 5400×2330×2020mm |
| Weight | 7200KG |
| Power | 90KW |
| Drilling Components | |
| 1.Hammer | HD45S |
| 2. Dia. Of rod | Φ76mmm |
| 2.Length of Rod | 3m |
| 3. Dia.of Bit | Φ115mm |
Match the air compressor LGCY-17/14.5
Working pressure:210PSI
Capacity: 600 CFM
Power:110kw
LGCY17/14.5 Diesel Driven portable Screw Air Compressor | |
Air compressor | |
Model No: | LGCY17/14.5 Kaishan brand |
Air capacity(m³/min/cfm) | 17(600) |
Work pressure(Bar/Psig) | 14.5(210) |
Fluid capacity(L) | 48 |
Compression Stage | Single |
Diesel Engine | |
Engine Model No. | Cummins 6BTA8.3-C260 |
Cylinder bore stroke number of cylinders | 114*135*6 |
Capacity (L) | 8.3 |
Rated RPM (r/min) | 1800 |
Unload RPM(r/min) | 1400 |
Rated Power (KW/hp) | 194(260) |
Fuel Capacity(L) | 380 |
Package | |
Noise level db (a) | 80±3 |
Outlet connection | G2*1,G¾*1 |
Wheel size * Qty | 6.5-16x4 |
Dimension/mm | 3650*1800*2500 |
Weight(KG) | 3370 |
