Colored tile making machine/ Concrete tile machine KB-125C

Brand:aa

Product detail:



Colored tile making machine/ Concrete tile machine KB-125C





KB-125C is automatically controlled and easy to operate, so it just needs 3- 7individuals to do the job.
Roof tile Work flow: Elevating--- Mixing --- Fixed-quantity filling --- Pressure forming --- Mould unloading --- Forming tiles --- Onto the tiles shelf ---Maintenance (24 hours) --- Stacking --- Natural maintenance --- Ink jetting --- Finished products.

Floor tile work flow: Elevating - Mixing - Fixed-quantity filling -Pressure forming -Mould unloading - Forming tiles - Maintenance - Finished products







The production line Roof tile making machine,concrete roof tile machine,KB-125C Tile forming machine is automatically controlled and easy to operate, so it just need 3-5 individuals to do the job.



There is no special need for the structure  Roof tile making machine,concrete roof tile machine,KB-125C Tile forming machine for sale tiles ; as long as the squre up to 150m2, and the height is no lower than 4m. the factory plot need't too large, but the outside field must be large enough for stacking the large qty.



The whole production line Roof tile making machine,concrete roof tile machine,KB-125C Tile forming machine  for the roof tiles --

capacity: 22.2 kw (pls see to that, not an usage in the meantime)

motor power of main equipment 5.5kw + motor power of constant feeder system 1.5kw + motor power of blender 5.5 kw + motor power of elevating conveyor 2.2 kw + motor power of the air compressing machine 7.5kw)



The electric vlotage and grequency: AC-380V/50HZ



The whole production line Roof tile making machine,concrete roof tile machine,KB-125C Tile forming machine for the floor tiles  ---

catacity: 30.5 kw (pls see to that, not an usage in the meantime)

motor power of main equipment 5.5 kw + motoer power of constant feeder system 1.5kw + motor power of blender 5.5 kw + motor power of elevating conveyor 2.2lw + automatic polishing machine: 15.8kw.





basic specification:



moulding presure	125T
moulding speed	7-8pcs/min,more than 3000pcs/shift
main frame power	5.5 KW
main frame weight	about 5T
external dimension	2700*1600*2480mm







details information pls kindly view following:

1)Its with the merits of fast molding speed, large output, reliable performance, PLC automatic control and convenient operation. Its hydropneumatic, with the speed as high as 7-8 pieces/min. 3000-3500pcs/shift=8hours/day.In addition, the rate of finished products is high, and the quality-price-relative is better.



2)The cement-tiles made of the mortar concrete with press-filtering molding are with the perfect structure. In addition, there are many kinds available, with high density, strong intensity, and nice dimensions, which are the excellent on the concrete products, meeting the different construction requirements





3)The machine is with multi - functional. By changing molds, it could be used to produce master tile, ridge tile, edge tile, drain-tile, etc. In addition, it could also be used to product various top-grade colorful ground tile, including terrazzo tile, bathing tile, etc.





machine sample:













roof tile samples:









functional products sample:
