QTY4-15A cement block machine for block factory

Brand:aa

Product detail:

QTY4-15A cement block machine for block factory



A: Production capacity of QTY4-15A as following:

The type QTY4-15A can produce all kinds of hollow blocks and solid bricks and color paving bricks,

only by changing different moulds.



B: Technical parameters of QTY4-15A:

Main machine size	3.5x2.2x3m		Pallet size	900x550mm
Main machine power	31.6kw		Weight	12.5Ton
Test pressure	16Mpa/cm2		Mixer	JS500
Vibration forece	45kn		Belt conveyor	8m
Forming cycle	12-20seconds		Voltage	380v/3phase



C:  QTY4-15A hollow block making machine other information:

1. Area: Workshop area: 150-200m2, all factory area 3000m2, the bigger, the better.

2. Workers :  five or eight.

3. Ratio of raw material:cement 8%-10% sand 30%-40% stone:50%-60%,about cement :sand : stone is1:4:5.

4.hollow block weight::

(390*190*190) :17KG,(190*140*190):13.5KG,(390*90*190):10KG

5. raw material consumption per day:100-130T

6. water consumption per day:3%-5% of raw material Weight.



D.QTY4-15A block making machine guarantee:

Our hollow block making machine is of one year guarantee,during the period we could supply spare parts if they are broken.



E.QTY4-15A block making machine production pressure:

Hollow blocks can reach 8-10Mpa,Solid bricks can reach 20-42Mpa,so they have a high pressure,can be used widely.
