Decanters/decanter centrifuges/centrifugal decanter

Brand:aa

Product detail:

Decanters/decanter centrifuges/centrifugal decanter



2-phase decanters – also called clarifying decanters – are employed for continuously separating solids from liquids with high solid contents. The bowl's high speed of rotation in these centrifugal decanters causes the solids to deposit on the bowl walls from where the built-in screw conveyor continuously transports them to the outlet from where they are discharged. The clarified liquid that is then almost completely free of solids leaves the separation chamber through openings at the other end of the bowl.



3-phase decanters are used to clarify and simultaneous separate liquids of different densities. The bowl's high speed of rotation in this centrifugal decanter causes the solids to deposit on the bowl wall from where the built-in screw conveyor continuously transports them to the outlet from where they are discharged. The separated liquid phases that are then almost completely free of solids leave the separation chamber through separate openings at the other end of the bowl.



Technical parameters:

Models	Basket Dia(mm)	Length-Diameter Ratio	Rotation rate of basket(r/min)	Relative Centrifugal force	Power of motor(Kw)	Weight(kg)	Overall Dimensions(l*w*h)(mm)
LW220*660	220	3	4800	2840	7.5-11	900	1650*1150*700
LW220*880	220	4	4300	2280	7.5-11	1000	1850*1200*750
LW300*1140	300	3.8	3750	2370	11-15	1500	2100*1300*650
LW355*1160	350	3.3	4000	3100	22	2020	3067*920*1060
LW355*1460	350	4.1	4000	3100	22	2200	3365*920*1060
LW400*1200	400	3	3500	2750	18.5-22	2500	2400*1650*900
LW420*1680	420	4	3600	3000	22	2430	3320*1000*1060
LW450*1350	450	3	3500	3080	30	2230	3750*1090*1250
LW450*1800	450	4	3500	3080	30-37	3500	4200*1090*1250
LW530*1800	530	3.4	3200	3040	45-55	3920	4565*1230*1350
LW530*2120	530	4	3200	3040	45-55	4200	4885*1230*1350





Paets of decanter centrifuges:
