Labor saving coconut oil expeller machine

Brand:aa

Product detail:

Labor saving coconut oil expeller machine



Introduction of coconut oil expeller machine

Automatic screw oil press is widely used to process peanut, soybean, rapeseed, cottonseed, sesame, sunflower, palm kernel, died copra, grainy oil plant seeds as well as corn germ, etc. into high quality edible oil. Equipped with automatic temperature-controlling and oil-filtering device, automatic screw oil press is more efficient and labor-saving.

Features of coconut oil expeller machine

1. Can be used for both hot press and cold press.

2. High oil yield and good condition oil cake.

3. High purity edible oil. As equipped with two vacuum oil tanks to filter pressed oil, the finished oil is of high purity.

4. The wear parts such as the pressing rings, worms are made of the carbon steel which is under the process of heat pretreatment, making them very durable.

5. Safety and convenience. The whole process is controlled by electric cabinet, making it more safe and easy to operate.

6. Cast iron machine base.

7. Special gear box structure make the rotating speed averagely.

8. Main parts of chamber through the processing of high-temperature tempering and low temperature quenching.

The main parts of coconut oil expeller machine

1. Screw oil press

2. Electrical element for heating chamber .

3. Vacuum filter for clean crude oil

4. Squeezing bolt

5. Heating ring.

Main datas of 6YL-130A coconut oil expeller machine

Model: 6YL-130A

Capacity: 400~500kg/h

Power: 18.5KW

Voltage: 380V (or as your requirement)

Packing size: 2500*1200*1900mm

Net weight: 1150kg

Gross weight: 1260kg

Single oil press parameters:





Model	Capacity (T/day)	Power (KW)	Weight (Kg)	Dimension (mm)
6YL-68	1	5.5	135	1050*660*760
6YL-80	2.5-3	5.5	340	1320*440*695
6YL-95	3-5	11	430	1910*610*765
6YL-120	4-7	11	720	2060*610*770
6YL-120C	6-8	15	730	2320*700*780
6YL-130	9-12	18.5	950	2020*700*780
6YL-160	14-18	22	1200	2120*800*980
6YL-180	15-20	30	1320	2700*720*800





Automatic oil press parameters:

Model	Capacity (T/day)	Power (KW)	Weight (Kg)	Dimension (mm)
6YL-80A	2.5-3	5.5	380	1320*550*750
6YL-95A	3-5	7.5	500	1930*630*780
6YL-120A	4-7	11	750	2075*630*780
6YL-120AC	6-8	15	760	2320*790*790
6YL-130A	9-15	18.5	1000	2030*720*790
6YL-160A	14-18	22	1300	2130*870*1010
6YL-180A	15-20	30	1420	2720*880*1110



Pictures of automatic oil press:









Pictures of single oil press:









If there is any problem about our coconut oil expeller machine, pls contact me directly.
