Brand:aa
Product detail:
MD1 electric wire rope hoist
capacity:2t
lifting height:6m
lifting speed:8/0.8m/min
travelling speed:20m/min
wire rope type:D-6*37+1
I-beam track type:20a~32c
Min.radius of curve(m):2~4
working duty:M3
power:380V/50HZ/3P
technical data:
| Type | CD1electric wire rope hoist | |||||||
| Capacityt(t) | 0.5 | 1 | 2 | 3 | 5 | 10 | ||
| Lifting Height(m) | 6-24 | 6-30 | 6-30 | 6-30 | 6-30 | 9-30 | ||
| Lifting Speed(m/min) | 8 | 8 | 8 | 8 | 8 | 7 | ||
| RunningSpeed(m/min) | 20,30 | |||||||
| Wire rope Type | 6x37-4.8-180 | 6x37-7.4-180 | 6x37-11-155 | 6x37-13-170 | 6x37-15-200 | 6x37-15-200 | ||
| Lifting Motor | Model | ZD1 12-4 ZDS1 0.2/1.5 | ZD1 22-4 ZDS1 0.2/1.5 | ZD1 31-4 ZDS1 0.4/3 | ZD1 32-4 ZDS1 0.4/4.5 | ZD1 41-4 ZDS1 0.8/7.5 | ZD1 51-4 ZDS1 1.5/13 | |
| Capacity(Kw) | 0.8 | 1.5 | 3 | 4.5 | 7.8 | 13.0 | ||
| R.P.M(r/min) | 1380 | 1380 | 1380 | 1380 | 1400 | 1400 | ||
| Running Motor | Model | ZDY1 11-4 | ZDY1 11-4 | ZDY1 12-4 | ZDY1 12-4 | ZDY1 21-4 | ZDY1 21-4 | |
| Capacity(Kw) | 0.2 | 0.2 | 0.4 | 0.4 | 0.8 | 0.8X2 | ||
| R.P.M(r/min) | 1380 | 1380 | 1380 | 1380 | 1380 | 1380 | ||
| 3P 380V 50Hz | ||||||||
