Brand:aa
Product detail:
3.0 T mini spider crane,expert in narrow space,crawler crane
Details:
- Mainly used in narrow space where large crane can not be used.
- Can be driven by gasoline or electric motor.
- Can realize the wireless remote control operation.
- Can use in aloft work with a hanging basket.
Application:
suspension setting of tombstone/glass,Construction and installation for railway,venues,
municipal works,electric power project,chemical pipeline,and so on.
Crawler crane Parameters:
Model | AZS-ZDQ3.0 | |
Specifications | 3.0t×1.3m | |
Maximum operating radius | 8.3m | |
Maximum raising height | 9.2m | |
Winding | Hook up speed | 2.5m/min(4) |
Cable diameter & length | ¢8mm×50m | |
Telescopic | Boom form | 5(5 Automatic) |
Boom length | 9m | |
Up and downs | Boom angle | 0-75° |
Rotation | Rotation angle | 360-degree continuous rotation |
Outrigger | The form of outrigger | The first paragraph automatic |
Maximum extending range | 3.4m×4.3m | |
Walking device | Walk way | Hydraulic |
Walking speed | 0-2.8km/h | |
Crawler belt | Synthetic rubber | |
Climbing Capacity | 20° | |
Ground pressure | 51kpa | |
Hydraulic | Hydraulic oil tank capacity | 80L |
Dimensions | L*W*H | 2.85m*0.8m*1.45m |
Gasoline engine and electric motor parameters:
Gasoline engine | Model | GX390 |
Output volume | 389.2ml | |
Maximum output power | 6.6KW | |
Starting method | Transistor magnet ignition (contactless) | |
The way of gasoline | Four-stroke, single cylinder, air cooling | |
Sense of rotation | Anticlockwise | |
Starting performance | 30(-5°C~40°C) | |
Accumulator capacity | 12V 32Ah | |
Electric motor | Three-phase asynchronous ac motor | 4KW |
Application pictures of the crawler crane:
Optional device:
