Quality assured JZM series concrete mixer
Technical features of JZM series concrete mixer (Gear-transmission)
1. JZM series of concrete mixer is a kind of gravity stabilized two-cone reverse tilting concrete mixer, the Mixing roller is driven by gear wheels, when it does positive rotation, the machine is stirring, or it will discharging, this mixer can stir plastic concrete and semirigid /hard concrete. It applies for construction site, road, bridge projects and all kinds of concrete componet factory.
2. The JZM series of mixers are designed and manufactured according to Concrete Mixer Tchnological Conditions GB/T9142-2000, it is an advanced machine which has resonable structure, high productivity, good mixing quality, graceful outline and convenient relocation, etc.
3.The series of mixers include five main moldes: JZM250, 300, 350, 500 and 750, but JZM750 is fixed molde, which besides used as a single machine, it can form a simple mixing plant when it is connected with batching machine. The rest molde is moveable.
Main parameters and description of JZM series concrete mixer(Gear-transmission)
Type | JZM250 | JZM350 | JZM500 | JZM750 | |
Opreation performance | Discharging capacity | 250L | 350L | 500L | 750L |
Feeding capacity | 320L | 560L | 800L | 1200L | |
Productivity | 6-8m3/h | 10-14m3/h | 18-20m3/h | 20-22m3/h | |
Mixing roller speed | 17r/min | 14r/min | 13r/min | 13r/min | |
Max.aggregate diameter | 60mm | 60mm | 60-80mm | 60-80mm | |
Precision | error ≤ 2% | error ≤ 2% | error ≤ 2% | error ≤ 2% | |
Motor | Mixing motor | 4kw | 5.5kw | 11kw | 11kw |
Elevator | 4kw | 4.5kw | 5.5kw | 7.5kw | |
Pump motor | 0.55kw | 0.55kw | 1.1kw | 1.1kw | |
Tire specification | 6.50-16 | 6.50-16 | 7.50-16 | ||
Max.dragging speed | 20km/h | 20km/h | 20km/h | ||
Overall dimension (L×W×H) | 2260 *1990 *2750mm | 2766 *2140 *3000mm | 5226 *2200 *5460mm | 6116 *2056 *6060mm | |
Total weight | 1300kg | 1950kg | 3100kg | 4200kg | |
