Huge tent for events for security check in size 40*70m

Brand:aa

Product detail:



Product Description

1)Application:

The Huge tent for events for security check in size 40*70m (XLS series, A frame) can be widely used as the wedding tent, party tent, exhibition tent, conference tent, different kinds of festivals tent, hajj tent, corporate events tent, sports tent, & temporary, semi-permanent or permanent building purpose etc.

2)Materials:
Fabric: Double PVC coated polyester fabric, 650-900g/sq. m, water proof, UV resistance, anti-mildew, self-cleaning, fire retardant according to standard NFPA701 & DIN4102 B1/M2



3)Frame:

Hard pressed extruded aluminum 6061/T6, anodized surface finishing.

Main frame profile size: 300*120*5mm ;



4)Connections:

Hot-dip galvanized steel;



5)Life span:

Life span of fabric(cover & sidewalls): 8-10years;

Life span of aluminum frame: 20-30years



6)Structure safety parameters:

Wind load: 100km/h (0.5kn/M2)

Snow load: 25kg/sq.m



7)Color available:

White, red, yellow, blue, green, black, grey, transparent etc



8)Optional Accessories:
Ground anchor, anchor puller, weight plate, glass door, fire door, glass wall, ABS hard wall, Sandwich walls, auto-rolling door, decoration lining, flooring system, clear PVC windows sidewalls, transport rack for the glass door & walls, ramp etc; chairs , tables, & other furniture for the parties are also provided for your option.



Specification for the  Huge tent for events for security check in size 40*70m (XLS series, A frame), pls refer to chart:

Type	Span (m)	Side height (m)	Ridge height (m)	Bay Distance (m)	Roof Pitch	Longest Component (m)	Wind Load (km/h)
XLS15/4-5AT	15	3.9	5.4	5	18°	10	100
XLS20/4-5AT	20	3.9	6.3	5	18°	10	100
XLS25/4-5AT	25	3.9	7.2	5	18°	10	100
XLS30/4-5AT	30	3.9	7.8	5	18°	10	100
XLS40/4-5AT	40	3.9	9.6	5	18°	10	100



Main frame Profile	300x120x5mm(4-channel)
Eave Connection	Hot-dip Galvanized Twin Steel Plate
Roof Fixing	Bar Tension
Frame Material	Hard Pressed Extruded Aluminum 6061/T6
Cover Material	Double PVC coated Polyester textile, flame retardant to DIN4102 B1,M2,750-900g/sq.m

  *Specialized in Producing different sizes of tents  base on unique requirements
