| Specification | Unit | GZZ(GDZ)-100 | GZZ(GDZ)-70 | GZZ(GDZ)-50 | GZZ(GDZ)-30 | GZZ(GDZ)-15 |
| Capacity | kg | 100 | 70 | 50 | 30 | 15 |
| Rolling container dimension | mm | Ф1470×1180 | Ф1320×1000 | Ф1160×1000 | Ф960×860 | Ф780×575 |
| Motor power | km | 3 | 2.2 | 1.5 | 1.1 | 0.55 |
| Fan power | km | 2×1.5 | 1.5 | 1.5 | 1.1 | 0.55 |
| Rolling container speed | rpm | 30 | 30 | 32 | 32 | 45 |
| Steam pressure | Mpa | 0.4-0.6 | 0.4-0.6 | 0.4-0.6 | 0.4-0.6 | 0.4-0.6 |
| Power consumption | kg | 3.2 | 2.4 | 1.8/29 | 1.2/15 | 0.75/9 |
| Steam consumption | kg | 100-120 | 80-100 | 50-60 | 25-30 | 18-25 |
| Electric haeting power | Kw | 48 | 39 | 30 | 18 | 9 |
| Machine dimension | mm | 1605×1930×2400 | 1460×1800×2230 | 1282×1600×2050 | 1060×1400×1780 | 870×1100×1460 |
| Machine weight | kg | 1500 | 1000 | 800 | 580 | 320 |
Product advantage
1.Drum in stainless steel, prevent the pollution of corrosion to fabric.
2.Fully automatic computer control the temperature, temperature control devices, over-temperature protection device.
3.Easy-to-use microprocessor.
4.Optimal design of cooling fan, with the best heat dissipation, wind speed.
5.The heat exchanger looks like wings, high thermal efficiency, long service life.
6.Dryer with gas heating system has the advantages such as fast heat exchange,low heat consumption and high heat-using.
7.Drawer-type filter,easy for cleaning;larger diameter fan will avoid stop up by woolen so that keep blowing clearly.
8.Security: Automatic temperature control system, automatic ignition and testing flame system.alarm and cut down gas inlet while no flame
Packaging & Delivery
Packaging & Delivery
| Packing Detail: | Wooden Case Packing of Heavy duty washing machine |
| Delivery Detail: | Shipped in 15 days after payment |
Picture show
