Function

• Continuity on protective conductors with 200mA
• Continuity on protective conductors with 10A
• Insulation resistance
• Tripping time and current of RCDs (type A, AC, general and selective)
• Line and Loop impedance and prospective short circuit current
• Loop impedance with high resolution (with IMP57 optional accessory)
• Global Earth Resistance without RCDs tripping
• Earth resistance with 3-wire and 2-wire methods
• Ground resistivity with 4-wire method
• Contact voltage
• Phase rotation
• TRMS measure and recording (Voltages, Currents, Powers, etc)
• Harmonic analysis of voltage and current up to the 49th order
• Voltage anomalies (sags, spikes, breaks) with a 10ms resolution
• Measurement and recording to leakage current to earth
• Measurement and recording of Temperature  (°C/°F), Humidity (HR%)
• Measurement and recording Illuminations (Lux)
• Save results inside memory
• Recall measured test at display
• Interface for PC communication
• Auto Power OFF
• Backlight

Codmetel : HV000057

Accessories

STANDARD

• C2033X : Cable 3 wires with Shuko plug
• KITGSC5 : Set 4 cables + 4 alligator clips + 2 test leads
• KITTERRNE : Set 4 cables + 4 metal probes
• C5700 : Power cord for test 10A
• TOPVIEW2006 : Windows software + optical/USB cable C2006
• BORSA2051 : Soft carrying bag
• User manual
• ISO9000 calibration certificate

OPTIONAL

• HTFLEX3003 : Set of 3 flex clamp 300-3000A AC, diameter 174mm
• HT96U : Rigid clamp 1-100-1000A AC, diameter 54mm
• HT97U : Rigid clamp 10-100-1000A AC, diameter 54mm
• HP30C2 : Rigid clamp 200-2000A AC, diameter 70mm
• HP30C3 : Rigid clamp 3000A AC, diameter 70mm
• HT4005N : Rigid clamp 5-100A AC, diameter 20mm
• C7000/05 : Set cables for 10A test, 5m lenght
• C7000/10 : Set cables for test 10A, 10m lenght
• IMP57 : Accessory for high resolution Loop/Line Impedance
• HT52/05 : Air temperature/humidity probe
• HT53/05 : Illuminance (Lux) probe
• HT903 : Accessory for connection to external CTs
• A0050 : External adapter 230V AC/12VDC
• A0053 : External adapter 110VAC 60Hz/12VDC
• 1066-IECN : Connector for banana cables, black colour
• 1066-IECR : Connector for banana cables, red colour
• CN0050 : Set of straps for use of meter on neck
• 606-IECN : Connector with magnetic test lead

Standards

EMC 2004/108/CE Directive

CE MARK
IEC/EN61557-1
IEC/EN61557-2
IEC/EN61557-3
IEC/EN61557-4
IEC/EN61557-5
IEC/EN61557-6
IEC/EN61557-7
LVD 2006/95/CE Directive
VDE 0100
